LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon

Brand Name : Cablein

Certification : CE, ROHS, TUV , ETL

Place of Origin : Shenzhen China

MOQ : 100PCS

Price : The price ranges from $1 to $4 USD per pieces

Payment Terms : T/T,Western Union

Delivery Time : 5-8 Working Days

Packaging Details : High Quality export carton

Assembly Wire : Soldering Or Screw Fitting

Operating Temperature : -40°C to +85°C

Interface Type : AC/DC

Contacts Number : 2-12 pins

Connector Type : Waterproof Connector

Voltage Rating : 250V

Protection Level : IP67

Connection : terminal box/compensation cable/head

Contact Now

LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite
Specifications
  • Pin: 5 Pin
  • Current Rating(A): 10A Max
  • Material: Metal+plastic
  • Conenction Way: Push-button snap fastener
  • Operating Voltage: 500V Max
  • Assembly Wire: IP-Rated Locking Gland
  • Mounting Type: Flange Mounting Type
  • Out Door UV Resistance: Pass
  • Cable Jacket OD: 1-1.5 mm²
LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite datasheet
Pins Number 2Pins 3Pins 4Pins 5Pins 7Pins 9Pins 12Pins
Rated Voltage 500V
250V
Rated Current 20A 10A 5A
Insulation voltage 2.5KV 1.5KV
IP CODE IP68
Cable Jacket OD Standard Power:⌀8-12mm Standard Signal :⌀5-6.5mm Other:⌀5-9mm
Assembly cable diameter 2.4-4mm²/14-12AWG 1-1.5mm²/18-16AWG 0.34-0.75mm²/22-20AWG
Ambient temperature -40℃~+80℃
LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite Advantages:
  1. Material & Performance:
    The housing is made of high-performance PBT engineering plastic, ensuring stable electrical properties, excellent heat resistance, and corrosion resistance. The gold-plated conductive components guarantee superior conductivity and meet temperature rise requirements even in high-temperature environments.
  2. Secure Locking Mechanism:
    Features a push-to-lock snap-fit design for secure mating and smooth insertion/removal.
  3. Waterproof Design:
    Standard IP67 rating (IP68 optional) provides precise waterproof protection.
  4. Certifications & Compliance:
    Complies with TUV, ISO, CE, and RoHS certifications, meeting global market requirements.
LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon
LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite Application industries
  • Automation Equipment
  • LED Lighting
  • Security Equipment
  • Telecommunication Equipment
  • New Energy
  • Electronic Devies
LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type Drawing
LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon
FAQ
Q: What makes this connector truly waterproof, and what is its IP rating?
A:This LP20 connector is engineered for superior sealing performance. It achieves an IP68 rating when properly mated, which is the highest level of ingress protection commonly certified for connectors. This means it is completely dust-tight (6) and can withstand continuous submersion in water beyond 1 meter depth (8), making it ideal for harsh outdoor, marine, or industrial environments. The waterproofing is achieved through precision-mated silicone seals within the connector body and a robust interface seal between the plug and socket.
Q: Why is the housing made from a Metal and Nylon composite, and what are the benefits?
A:The hybrid metal and nylon composite construction offers the best of both worlds. The metal parts (typically the flange and shell) provide exceptional EMI shielding protection, structural rigidity, and resistance to crushing impacts. The nylon components offer high corrosion resistance, excellent dielectric insulation, and are lightweight, which reduces overall weight and prevents galvanic corrosion. This combination results in a connector that is far more durable and reliable in demanding applications than all-plastic versions, while offering significant advantages over heavier all-metal designs.
